20A Suntree Dc Link With 1 Pole Holder

20A Suntree DC Link with 1 Pole Holder – High-Performance DC Protection for Solar Systems

The 20A Suntree DC Link with 1 Pole Holder is a high-quality DC fuse link assembly designed for reliable protection and stable current distribution in solar PV systems, inverters, and DC electrical installations. It ensures safe operation by protecting circuits from overload, short-circuit faults, and PV string failures, making it an essential component in modern renewable energy systems.

Engineered for durability and efficiency, this unit supports high-voltage DC applications up to 1000V, delivering consistent performance in both residential and commercial solar setups.

Key Features of 20A Suntree DC Link with 1 Pole Holder

• High Protection Performance
  Provides reliable protection for solar PV strings and DC circuits, preventing damage caused by electrical faults and reverse currents.
• Single Pole Holder Design (1P)
  Compact and space-saving configuration designed for easy integration into DC combiner boxes and distribution panels.
• High Voltage Capability (1000V DC Rated)
  Suitable for demanding solar energy systems and high-voltage DC applications.
• Quick Fault Isolation
  Automatically isolates faulty circuits to protect solar panels, inverters, and connected equipment.
• Durable & Heat-Resistant Construction
  Built using high-grade insulating materials for thermal stability, long service life, and safety under continuous load.
• DIN Rail Mount Compatible
  Designed for fast installation in standard electrical enclosures and solar distribution systems.

Technical Specifications

• Brand: Suntree
  • Product Type: DC Fuse Link with Holder
  • Pole Configuration: 1 Pole (1P)
  • Rated Current: 20A
  • Rated Voltage: Up to 1000V DC
  • Fuse Size: 10 × 38 mm
  • Application Type: DC / Solar PV systems
  • Protection Type: Overcurrent & short-circuit protection
  • Mounting Type: DIN rail compatible
  • Operating Temperature: -30°C to +70°C
  • Standards Compliance: IEC 60269-6 / PV system protection standards
  • Material: Flame-retardant, high-insulation thermoplastic body

Applications

The 20A Suntree DC Link with 1 Pole Holder is widely used in:

• Solar PV systems (string protection)
• Solar combiner boxes
• Inverter DC input protection
• Battery storage systems
• Off-grid and hybrid solar installations
• Industrial DC distribution systems

Why Choose the Suntree 20A DC Link?

The Suntree DC Link 20A delivers safe, stable, and efficient DC power protection for solar installations. It reduces system downtime, enhances electrical safety, and improves overall energy reliability in solar and DC applications.

It is a preferred choice for installers seeking a durable, high-performance, and cost-effective DC protection solution for modern energy systems.
