RACK SPLITTER 1 x 8 Module Type G657A1.
KSh 9,800.00
- 1 X 8, module type
- 0.9mm PVC fiber jacket G657A1
- with SC/PC connectors
- fiber length: 1m; ABS
- box size: 120mm x 80mm x 18mm
- Single fiber, SC/LC/ST/FC-based connector
- In-line connection available
- Operating temperature: -40° to 85°C
- Cable Diameter Range: 1.5mm, 2.0mm, 3.0mm,2.0*3.0mm
Description
Rack Splitter 1 x 8 Module Type G657A1 1260-1650nm 1.5m of input and output port.
The features of the PLC splitter are small size, high reliability, wide operating wavelength range, and good channel-to-channel uniformity. And It is widely used in PON networks to realize optical signal power splitting. TDK Solutions provides a whole series of 1xN and 2xN splitter products that are tailored for specific applications.
These Rack splitter can be used in the following Network Types:
- FTTx systems
- PON networks
- CATV links
- Optical signal distribution
- Broadband, CATV, telecom, data centers, LAN, WAN, medical, military and wireless
- Compliance
Rack Slitter 1 x 8 Module Type G657A1 Specifications.
- Low Insertion loss
- Low PDL
- Compact Design
- Good channel-to-channel uniformity
- Wide Operating Wavelength:
- From 1260nm to 1650nm
- Wide Operating Temperature: -40° to 85°C
- High Reliability and Stability
